Details
Built for racers obsessed with speed, performance, and control, the new Pique Advanced SL is engineered to deliver. Components are designed to work seamlessly together as one optimized system. The 120mm single-pivot FlexPoint Pro rear suspension is now semi-integrated with your top tube for a lighter, more efficient ride. And the flip chip lets you adjust your geometry for the course ahead and the fire inside.
Built for speed
The new Advanced SL-grade composite frame is the lightest we’ve ever designed, achieving exceptional stiffness-to-weight so you can punch up climbs, shoot out of corners, and sprint to the next section without hesitation. Tuned specifically for downcountry adventures, the reengineered FlexPoint Pro Suspension is lighter, more compact, and more responsive
Built for performance
The Pique X Advanced SL is designed as a single optimized system. The new one-piece handlebar-stem with fully integrated cable routing keeps things light, clean, and responsive. Giant WheelSystems with Wide Guard rims give you robust sidewalls so you can run lower tire pressure for extra grip and puncture protection.
Built for fun
The updated FlexPoint Pro suspension system offers 120mm of smooth, active rear-wheel travel, paired with a 130mm fork, keeping you glued to the trail when it’s rowdy, and efficient when it’s not. The two-position flip chip lets you adjust your geometry for the perfect handling for the terrain. And with built-in down tube storage, you’re ready to fix and fuel.
| Frame Size | XS | S | M | L |
|---|---|---|---|---|
| Seat Tube Length (mm) | 400 | 410 | 440 | 470 |
| Seat Tube Angle | 75.0° | 75.5° | 75.0° | 75.5° | 75.0° | 75.5° | 75.1° | 75.6° |
| Top Tube Length (mm) | 557 | 555 | 574 | 572 | 596 | 594 | 613 | 611 |
| Head Tube Length (mm) | 90 | 95 | 105 | 115 |
| Head Tube Angle | 66.0° | 66.5° | 66.0° | 66.5° | 66.0° | 66.5° | 66.1° | 66.6° |
| Fork Rake (mm) | 44 | 44 | 44 | 44 |
| Trail (mm) | 119.6 | 115.7 | 119.5 | 115.7 | 119.3 | 115.6 | 119.2 | 115.5 |
| Wheelbase (mm) | 1125 | 1124 | 1143 | 1142 | 1166 | 1166 | 1185 | 1184 |
| Chain Stay Length (mm) | 437 | 435 | 437 | 435 | 437 | 435 | 437 | 435 |
| Bottom Bracket Drop (mm) | 48 | 42 | 48 | 42 | 48 | 42 | 48 | 42 |
| Stack (mm) | 605 | 602 | 610 | 607 | 620 | 616 | 629 | 625 |
| Reach (mm) | 394 | 400 | 410 | 416 | 430 | 436 | 445 | 450 |
| Stand Over Height (mm) | 777 | 784 | 775 | 782 | 770 | 777 | 765 | 771 |
| Handlebar Width (mm) | 780 | 780 | 780 | 780 |
| Stem Length (mm) | 50 | 50 | 50 | 60 |
| Crank Length (mm) | 165 | 170 | 170 | 170 |
Specs
| Frame | Advanced SL-grade composite front and rear triangles, 120mm FlexPoint Pro suspension, flip chip, 12x148mm thru-axle, internal storage |
|---|---|
| Fork | Fox 34 Rhythm, 130mm, GRIP damper, Boost 15x110, 44mm offset |
| Rear Shock | Fox Float SL Performance, 210/50 |
| Tires | Maxxis Rekon Race 29x2.4, foldable, 120tpi, EXO, tubeless |
| Brakes | TRP Slate EVO hydraulic, stainless, 6-bolt rotors [F]203mm, [R]180mm |
| Rims | Giant XCA WheelSystem |
| Crankset | Praxis Cadet HD M24, 30t, 55mm chainline XS: 165mm, S:170mm, M:170mm, L:170mm |
| Bottom Bracket | Praxis, press fit |
| Shifters | Shimano Deore mechanical, 1x12 |
| Cassette/Freewheel | Shimano M6100, 10x51 |
| Rear Derailleur | Shimano Deore |
| Brake Levers | TRP Slate EVO |
| Handlebars | Giant Integrated XC, alloy, 780mm, 9-degree upsweep |
| Chain | KMC X-12 |
| Tape/Grips | Liv Tactal, lock on |
| Stem | Giant Integrated XC, alloy XS: 50, S:50mm, M:50mm, L:60mm |
| Seatpost | Giant Contact Switch AT dropper, remote XS:110-140mm travel / 30.9 x 395mm S: 110-140mm travel / 30.9 x 395mm M: 110-140mm travel / 30.9 x 395mm |
| Saddle | Giant Grit Core |
| Accessories & Extras | Tubeless prepared, 2.4" max tire size, 34t max chainring size, MRP SL TR2 chain guide |
| Hubs |
Front: Giant MTB alloy, 6-bolt Rear: Giant MTB alloy, 3-pawl driver, 6-bolt |
| Spokes | Sapim |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Mechanic Rose/Carbon / X-Small / 29-inch | 04711291212145 | 1072014103 |
| Mechanic Rose/Carbon / Small / 29-inch | 04711291212152 | 1072014104 |
| Mechanic Rose/Carbon / Medium / 29-inch | 04711291212169 | 1072014105 |
| Mechanic Rose/Carbon / Large / 29-inch | 04711291212176 | 1072014107 |
