Details
Built for racers obsessed with speed, performance, and control, the new Pique Advanced SL is engineered to deliver. Components are designed to work seamlessly together as one optimized system. The 120mm single-pivot FlexPoint Pro rear suspension is now semi-integrated with your top tube for a lighter, more efficient ride. And the flip chip lets you adjust your geometry for the course ahead and the fire inside.
Built for speed
The new Advanced SL-grade composite frame is the lightest we’ve ever designed, achieving exceptional stiffness-to-weight so every pedal stroke returns power almost effortlessly, for swift and decisive acceleration and climbing. Tuned specifically for XC racing, the reengineered FlexPoint Pro Suspension is lighter, more compact, and more responsive.
Built for performance
The Pique Advanced SL is designed as a single optimized system. The new one-piece handlebar-stem with fully integrated cable routing keeps things light, clean, and responsive. Giant WheelSystems with Wide Guard rims give you robust sidewalls so you can run lower tire pressure for extra grip and puncture protection.
Built for results
The updated FlexPoint Pro suspension system offers 120mm of smooth, active rear-wheel travel, paired with a 120mm fork, giving you the control and stability you need when things get technical. The two-position flip chip lets you adjust your geometry for the perfect handling for the course. And the suspension lock-out provides hardtail-like efficiency when you’re climbing a hill or a podium.
| Frame Size | XS | S | M | L |
|---|---|---|---|---|
| Seat Tube Length (mm) | 400 | 410 | 440 | 470 |
| Seat Tube Angle | 75.5° | 76.0° | 75.5° | 76.0° | 75.5° | 76.0° | 75.5° | 76.0° |
| Top Tube Length (mm) | 555 | 554 | 572 | 571 | 594 | 593 | 611 | 610 |
| Head Tube Length (mm) | 90 | 95 | 105 | 115 |
| Head Tube Angle | 66.5° | 67.0° | 66.5° | 67.0° | 66.5° | 67.0° | 66.5° | 67.0° |
| Fork Rake (mm) | 44 | 44 | 44 | 44 |
| Trail (mm) | 116 | 112 | 116 | 112 | 116 | 112 | 116 | 112 |
| Wheelbase (mm) | 1121 | 1120 | 1138 | 1138 | 1162 | 1162 | 1181 | 1180 |
| Chain Stay Length (mm) | 437 | 435 | 437 | 435 | 437 | 435 | 437 | 435 |
| Bottom Bracket Drop (mm) | 51 | 45 | 51 | 45 | 51 | 45 | 51 | 45 |
| Stack (mm) | 602 | 599 | 607 | 603 | 616 | 612 | 625 | 622 |
| Reach (mm) | 399 | 405 | 415 | 421 | 435 | 440 | 450 | 455 |
| Stand Over Height (mm) | 772 | 778 | 770 | 776 | 765 | 765 | 759 | 765 |
| Handlebar Width (mm) | 780 | 780 | 780 | 780 |
| Stem Length (mm) | 60 | 60 | 70 | 70 |
| Crank Length (mm) | 165 | 170 | 170 | 170 |
Specs
| Frame | Advanced SL-grade composite front and rear triangles, 120mm FlexPoint Pro suspension, flip chip, 12x148mm thru-axle |
|---|---|
| Fork | RockShox Sid Flight Attendant XC, 120mm, Flight Attendant Race Day damper, Boost 15x110, 44mm offset |
| Rear Shock | RockShox SidLuxe Flight Attendant, RL3 damper, Solo Air, 210/50 |
| Tires | Maxxis Aspen 29x2.4, foldable, 120tpi, MaxxSpeed, EXO, tubeless |
| Brakes | SRAM Motive ULT, hydraulic, SRAM HS2 CenterLock rotors [F]180mm, [R]160mm |
| Rims | XCR 29 carbon wheelsystem |
| Crankset | SRAM XX SL Eagle Transmission with Quark power meter, 32t, 55mm chainline XS: 165mm S:170mm, M:170mm, L:170mm |
| Bottom Bracket | SRAM DUB, press fit |
| Shifters | SRAM AXS Pod, 1x12 |
| Cassette/Freewheel | SRAM XS 1299 Eagle Transmission, 10x52 |
| Rear Derailleur | SRAM XX SL Eagle Transmission |
| Brake Levers | SRAM Motive ULT |
| Handlebars | Giant Integrated XC, composite, 780mm, 9-degree upsweep |
| Chain | SRAM XX SL Eagle Transmission |
| Tape/Grips | Liv XC Pro, silicone |
| Stem | Giant Integrated XC Carbon XS: 60, S:60mm, M:70mm, L:70mm |
| Seatpost | RockShox Reverb AXS, pod controller remote XS: 100mm travel / 30.9 x 395mm S: 100mm travel / 30.9 x 395mm M: 100mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 3 |
| Saddle | Liv Grit SL |
| Pedals | Sold Separately |
| Accessories & Extras | Tubeless prepared, 2.4" max tire size, 34t max chainring size, MRP SL TR2 chain guide |
| Hubs | Front: Giant MTB alloy, 6-bolt Rear: Giant MTB alloy, 6-bolt |
| Spokes | Carbon |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Stellar Purple / Medium / 29-inch | 04711291211360 | 1072012105 |
